Lithium Battery Solution for Smart Wearable Devices
Smart wearable devices are a general term for devices designed and developed by applying wearable technology to intelligently transform daily wearables. Examples include glasses, bands and watches, which are wireless and extremely convenient to use. Integrated with the Internet of Things and cloud computing, these intelligent and commercialized wearable products closely follow the development trend of the Internet era.
We are a professional manufacturer of lithium batteries for smart wearable devices, offering a complete range of models that are widely used in:
Sports & Fitness:
Mainly in the form of sports watches, sports bands and accessories, providing monitoring, analysis and services for sports and outdoor data such as heart rate, cadence, air pressure, diving depth, altitude and more.
Consumer Electronics:
Smart watches, smart glasses, Wi-Fi speakers, wearable multi-touch projectors, charging boots, fitness clothing, navigation shoes and more.
OCM New Energy lithium batteries can be customized to any voltage, capacity and shape according to your requirements. Contact us now to get a quick wearable device lithium battery solution!
I. OCM371229 Smart Wristband Battery Solution
| Product Model | OCM371229 |
| Nominal Capacity | 110mAh |
| Product Dimensions | 3.7×12×29mm |
| Nominal Voltage | 3.7V |
| Charge Voltage | 4.2V |
| Charge Temperature | 0°C ~ 45°C |
| Discharge Temperature | -20°C ~ +60°C |
| Storage Temperature | -20°C ~ +35°C |
| Charge Current | Standard Charge: 0.5C, Fast Charge: 1.0C |
| Standard Charging Method | 0.5C CC (Constant Current) charge to 4.25V, then CV (Constant Voltage 4.2V) charge until charge current ≤ 0.05C |
| Max Charge Current | 1C |
| Max Discharge Current | 1C |
| Protection IC Parameters | Over-charge Protection Voltage: 4.20V±0.05V
Over-discharge Protection Voltage: 2.7V±0.1V |
II. Features of the Smart Wristband Battery Solution
- Wide operating temperature range: -20℃ to 55℃
- Fast charging: supports repeated fast charging with no memory effect
- Light weight, high capacity, excellent low-temperature performance, supports high-rate charge and discharge
- Safe and reliable: built-in protection board against short circuit, overcharge, over-discharge, etc.
- Extra-long service life: capacity remains above 80% after 500 charge-discharge cycles
- High plasticity: customizable into special shapes such as arc, round, ultra-thin thickness, etc.
- Eco-friendly: certified with ISO 9001, UL, UN, CE, RoHS, REACH and more
III. Application Examples of Smart Wristband Battery Solutions
